The method involves using graphene to deposit nanomaterials in predefined locations without chemical contamination. In research described in the journal Nature Communications, the IBM researchers for the first time electrified graphene so that it helps to deposit nanomaterials with 97 percent accuracy.

The research was part of a $3 billion investment programme started by Big Blue four years ago  dubbed "7nm and Beyond".

Mathias Steiner, manager at IBM Research-Brazil, said: "As this method works for a wide variety of nanomaterials, we envision integrated devices with functionalities that represent the unique physical properties of the nanomaterial."

"We also can envision on-chip light detectors and emitters operating within a distinct wavelength range determined by the optical properties of the nanomaterial."

As an example, Steiner explained that if you wanted to modify the spectral performance of an optoelectronic device, you could simply replace the nanomaterial while keeping the manufacturing process flow the same. If you take the method one step further, you could assemble different nanomaterials in different places doing multiple passes of the assembly to create on-chip light detectors operating in different detection windows at the same time.
